Archive for May, 2018

MMX – speed up your Delphi development, now maintained by Raabe Software

Posted by jpluimers on 2018/05/23

New home [WayBackMMX – speed up your Delphi development

Old home [WayBack] ModelMaker Tools

Thanks a lot to Gerrit Beuze for al the efforts and insights while he created and maintained MMX for such a long time

Thanks a lot to Uwe Raabe for taking over the maintenance and providing the binaries for free.

I have posted links to some archived site pages below, just in case anybody needs them (when QC went off-line after a while the Google Search failed to show search results for this; hopefully this will keep some of the information retrievable).

As a follow up to:

–jeroen

Archived links (in semi-random order) hopefully they survive the shutdown of the links:

Read the rest of this entry »

Posted in Delphi, Development, Software Development | 1 Comment »

How does a relational database work – Coding Geek

Posted by jpluimers on 2018/05/23

An in-depth article that explains how a relational database handles an SQL query and the basic components inside a database.

Long read with good illustrations, worth every minute of your time: [WayBackHow does a relational database work – Coding Geek

Via: [WayBack] Quite interesting article not just about how to use relational databases but about how the various parts of them work. via +John Kouraklis – Thomas Mueller (dummzeuch) – Google+

As it is so long, here is the table of contents so you can get going:

–jeroen



Posted in Development, Software Development | Leave a Comment »

Delphi – when compiling consts doesn’t work…

Posted by jpluimers on 2018/05/23

Delphi has a lot of loose ends. With the extension of the language, it gets more and more. Or as Stefan Glienke formulated it:

It should all compile but it does not because currently what is a real const and what is a variable treated as const by the compiler is a f…ing mess and thus some combinations don’t work. If you have watched that C++ session recently posted here you know how const should be handled by a compiler in 2017.

[WayBack] The recent next gen compiler debate reminded me of this nice talk.This is about c++ but it shows off nicely what a high quality compiler can achieve in… – Christoph Hillefeld – Google+

Source [WayBackI don’t need a solution for this but wonder if Elements4 should compiles or not… – Paul TOTH – G+

–jeroen

Read the rest of this entry »

Posted in Delphi, Development, Software Development | Leave a Comment »

Delphi WSDL importer compiler defines

Posted by jpluimers on 2018/05/22

As a follow-up on Delphi WSDL default importer settings, you can use these compiler defines to increase output.

Output that the built-in Wizard will never show you (that is also the reason you will not see any errors like access violations in the IDE).

TL;DR

Always use the command-line WSDL importer WSDLImp as it has the same default options as the IDE.

The command-line WSDL importer called WSDLImp does show error messages, but in case of an error still continues writing the wrong .pas file.

Syntax:

"C:\Program Files (x86)\Embarcadero\Studio\19.0\bin\WSDLImp.exe" -DD:\Playground\iECK_ImportWSDL "D:\Playground\iECK DT2.0 services v2.1.1\wsdl\ECK-DT2-CatalogService-v2.1.1.wsdl"

When debugging the code, I found out there are many conditional defines you can enable so it shows more output. Output that greatly helps to pin-point issues while importing more complex WSDL, especially when the WSDL has include or import elements.

These are the defines:

  • TRACK_MEMORY this requires the FastMM4 unit in the path
  • SHOW_XML_INFO
  • LOG_TYPES_DUMP
  • LOG_TYPES_LOOKUP
  • LOG_TYPES_READING
  • LOG_TYPES_SORTING
  • LOG_TYPES_UNWIND
  • LOG_TYPES_WRITING

The really odd thing is that there is a hidden command-line option -debug which does not automatically enable these, but does use SHOW_XML_INFO which seems enabled by default and writes an output file with extension .xml in addition to .pas, where the XML has an overview of the parsed data types.

I am going to fiddle around to see if I can enable all of the LOG_ entries from the command-line in a simple way.

When you debug the WSDLImp tool, ensure these two directories are on the unit search path:

  • $(BDS)\source\soap
  • $(BDS)\source\xml

The first is needed so the compiler can find CompVer.inc, the second so you can step through the XML handling code.

Also make sure you change the output path from $(BDS)\bin (which only works under UAC and overwrites the stock output) with something like .\$(Platform)\$(Config) (which  puts it along the .DCU files).

–jeroen

Posted in Delphi, Development, Software Development | Leave a Comment »

Delphi Are you familiar with “forgotten” hints? Here is a very rough example how to get rid of them…

Posted by jpluimers on 2018/05/22

Thanks for [WayBack] Are you familiar with “forgotten” hints? Here is a very rough example how to make them disappear without restarting the IDE… – Attila Kovacs – Google+

The code is centered around enumerating all windows of class TDesignerHintWindow and closing them.

These Windows happen to me a lot more in Galileo based IDEs than the classic Delphi < 8 ones.

–jeroen

Read the rest of this entry »

Posted in Delphi, Development, Software Development | Leave a Comment »
