Archive for December, 2022

VMware ESXI: creating an eagerly zeroed thick disk

Posted by jpluimers on 2022/12/30

For my memory to create a 40 GiB (gibibytes, i.e. sizes in powers of 2 bytes):

# vmkfstools --createvirtualdisk 40G --diskformat eagerzeroedthick ./X9SRI-3F-W10P-EN-MEDIA-DATA.vmdk
Creating disk './X9SRI-3F-W10P-EN-MEDIA-DATA.vmdk' and zeroing it out...
Create: 100% done.

People tend to abbreviate it into what for me reads gibberish:

# vmkfstools -c 40G -d eagerzeroedthick ./X9SRI-3F-W10P-EN-MEDIA-DATA.vmdk
Creating disk './X9SRI-3F-W10P-EN-MEDIA-DATA.vmdk' and zeroing it out...
Create: 100% done.

It will create a descriptor file and flat data file, of which the last is exactly 40 gibibytes size (as 42949672960 / (1024 * 1024 * 1024) == 40):

# ls -l X9SRI-3F-W10P-EN-MEDIA-DATA*.vmdk
-rw-------    1 root     root     42949672960 Nov 16 16:54 X9SRI-3F-W10P-EN-MEDIA-DATA-flat.vmdk
-rw-------    1 root     root           471 Nov 16 16:54 X9SRI-3F-W10P-EN-MEDIA-DATA.vmdk

–jeroen

Posted in ESXi6, ESXi6.5, ESXi6.7, Power User, Virtualization, VMware, VMware ESXi | Leave a Comment »

“retrieving data with adventure sync” – Google Search

Posted by jpluimers on 2022/12/29

[Wayback/Archive] “retrieving data with adventure sync” – Google Search

Reboot only solved one widget, not the other. Turning off/on Adventure Sync didn’t fix either.

–jeroen

Posted in LifeHacker, PokemonGo, Power User | Leave a Comment »

Terugkijken | NPO Radio 2

Posted by jpluimers on 2022/12/29

Reminder to self: even opnieuw in het archief stoppen begin januari.

[Wayback/Archive] Terugkijken | NPO Radio 2

–jeroen

Posted in Uncategorized | Leave a Comment »

Chris Bensen on Raspberry Pi and clusters

Posted by jpluimers on 2022/12/29

Oracle’s Pi Supercomputer

Oracle’s Pi Supercomputer ; click on the image for a larger version.

In 2019 ans 2020, [Archive] Chris Bensen and his [Archive] Oracle Groundbreakers team built a really large Raspberry Pi cluster of more than 1k pies, all network booting to become a cluster. It was for instance covered in the [Wayback/Archive] Building the World’s Largest Raspberry Pi Cluster – DZone IoT.

On his [Wayback/Archive] personal blog, he wrote a few posts like [Wayback/Archive] Chris Bensen: Raspberry Pi Overlay Root Filesystem and [Wayback/Archive] Chris Bensen: Get MAC Address for a Pi Cluster.

It made me also bump into [Wayback/Archive] Building the world’s largest Raspberry Pi cluster early 2020,

Since that wast right after the start of my rectum cancer treatment which lasted longer and, because of I got metastases a few months after radiation treatment, required more treatments than anticipated, I put a note in my bog drafts and kind of lost track.

So I was glad that in fall 2021, I bumped into the draft and found an almost year old post [Wayback/Archive] Chris Bensen: All Raspberry Pi Super Computer Posts in One Spot which is an index in all the blog posts and videos that Chris and his team produced on this project.

I then also learned the cluster had been shown on [Wayback/Archive] Oracle OpenWorld 2019, Breakthrough Starts Here and was covered in the [Archive] Top 10 Raspberry Pi Projects of 2019 | Tom’s Hardware (where I got the [Wayback/Archive] Oracle World 2019 having the 1k+ node Raspberry Pi cluster on display picture shown on the right from).

Read the rest of this entry »

Posted in *nix, Development, Hardware Development, Linux, OracleLinux, Power User, Raspberry Pi | Leave a Comment »

Getting your public IP address from the command-line when http and https are blocked: use DNS

Posted by jpluimers on 2022/12/28

Years ago, I wrote Getting your public IP address from the command-line. All methods were http based, so were very easy to execute using cURL.

But then in autumn 2021, Chris Bensen wrote this cool little blog-post [Wayback/Archive] Chris Bensen: How do I find my router’s public IP Address from the command line?:

dig -4 TXT +short o-o.myaddr.l.google.com @ns1.google.com

At first sight, I thought it was uncool, as the command was quite long and there was no explanation of the dig command trick.

But then, knowing that dig is a DNS client, it occurred to me: this perfectly works when http and https are disabled by your firewall, but the DNS protocol works and gives the correct result:

# dig -4 TXT +short o-o.myaddr.l.google.com @ns1.google.com
"80.100.143.119"

This added the below commands and aliases to my tool chest for *nix based environments like Linux and MacOS (not sure yet about Windows yet :), but that still doesn’t explain why it worked. So I did some digging…

IPv4

  • command:
    dig -4 TXT +short o-o.myaddr.l.google.com @ns1.google.com
  • command removing outer double quotes:
    dig -4 TXT +short o-o.myaddr.l.google.com @ns1.google.com | xargs
  • alias:
    alias "whatismyipv4_dns=dig -4 TXT +short o-o.myaddr.l.google.com @ns1.google.com | xargs"

IPv6

  • command:
    dig -6 TXT +short o-o.myaddr.l.google.com @ns1.google.com
  • command removing outer double quotes:
    dig -6 TXT +short o-o.myaddr.l.google.com @ns1.google.com | xargs
  • alias:
    alias "whatismyipv6_dns=dig -6 TXT +short o-o.myaddr.l.google.com @ns1.google.com | xargs"

How it works

Let’s stick to dig and IPv4 as that not having IPv6 (regrettably still) is the most common situation today:

# dig -4 TXT +short o-o.myaddr.l.google.com @ns1.google.com
"80.100.143.119"

What it does is request the DNS TXT record of o-o.myaddr.l.google.com from the Google DNS server ns1.google.com and returns the WAN IPv4 address used in the DNS request, which is for instance explained in [Wayback/Archive] What is the mechanics behind “dig TXT o-o.myaddr.l.google.com @ns1.google.com” : linuxadmin.

Since these are TXT records, dig will automatically double quote them, which xargs can remove (see below how and why):

# dig -4 TXT +short o-o.myaddr.l.google.com @ns1.google.com | xargs
80.100.143.119

The DNS query will fail when requesting the Google Public DNS servers 8.8.8.8 or 8.8.4.4:

# dig -4 TXT +short o-o.myaddr.l.google.com @8.8.8.8
"2a00:1450:4013:c1a::103"
"edns0-client-subnet 80.101.239.0/24"

Or, with quotes removed (the -L 1 ensures that xargs performs the quote-pair removal action on each line):

# dig -4 TXT +short o-o.myaddr.l.google.com @8.8.8.8 | xargs -L 1
2a00:1450:4013:c1a::103
edns0-client-subnet 80.101.239.0/24

This request is both slower than requesting the ns1.google.com server and wrong.

The reason is that only ns1.google.com understands the special o-o.myaddr.l.google.com hostname which instructs it to return the IP address of the requesting dig DNS client.

That 8.8.8.8 returns a different IP address and an additional edns0-client-subnet with less accurate information is explained in an answer to [Wayback/Archive] linux – Getting the WAN IP: difference between HTTP and DNS – Stack Overflow by [Wayback/Archive] argaz referring to this cool post: [Wayback/Archive] Which CDNs support edns-client-subnet? – CDN Planet.

Not just ns1.google.com: any DNS server serving the google.com domain

Since o-o.myaddr.l.google.com is part of the google.com domain, the above works for any DNS server serving the google.com domain (more on that domain: [Wayback/Archive] General DNS overview  |  Google Cloud).

Getting the list of DNS servers is similar to getting the list of MX servers which I explained in Getting the IP addresses of gmail MX servers, replacing MX record type (main exchange) with the NS record type (name server) and the gmail.com domain with the google.com domain:

# dig @8.8.8.8 +short NS google.com
ns3.google.com.
ns1.google.com.
ns2.google.com.
ns4.google.com.

The ns1.google.com DNS server is a special one of the NS servers: it is the start of authority server, which you can query using the SOA record type that also gives slightly more details for this server:

# dig @8.8.8.8 +short SOA google.com
ns1.google.com. dns-admin.google.com. 410477869 900 900 1800 60

The difference between using NS and SOA records with dig are explained in the [Wayback] dns – How do I find the authoritative name-server for a domain name? – Stack Overflow answer by [Wayback/Archive] bortzmeyer who also explains how to help figuring out SOA and NS discrepancies (note to self: check out the check_soa tool originally by Michael Fuhr (I could not find recent content of him, so he might have passed away) of which source code is now at [Wayback/Archive] Net-DNS/check_soa at master · NLnetLabs/Net-DNS).

So this works splendid as well using ns4.google.com on my test system:

# dig -4 TXT +short o-o.myaddr.l.google.com @ns4.google.com | xargs
80.100.143.119

The xargs removes outer quotes removal trick

[Wayback/Archive] string – Shell script – remove first and last quote (“) from a variable – Stack Overflow (thanks quite anonymous [Wayback/Archive] user1587520):

> echo '"quoted"' | xargs
quoted

xargs uses echo as the default command if no command is provided and strips quotes from the input.

More on https versus DNS requests

Some notes are in [Wayback/Archive] How to get public IP address from Linux shell, but note the telnet trick now fails as myip.gelma.net is gone (latest live version was archived in the Wayback Machine in august 2019).

Via

–jeroen

Posted in *nix, *nix-tools, Apple, bash, bash, Batch-Files, Communications Development, Development, DNS, Internet protocol suite, Linux, Mac, Mac OS X / OS X / MacOS, Power User, Scripting, Software Development, TCP | Leave a Comment »
