The easiest way to enable remote desktop access on Windows is by running SystemPropertiesRemote.exe.
There are alternatives using the command prompt that edit registry settings and network firewall in the links below, but they are all more cumbersome.
Links mostly via enable remote desktop on windows – Google Search
I need to check out:
- which of the above are really old
- how to find out if WinRM is enabled
- see if this can be done over WinRM
- see if this can be done with PSShell
- see if PowerShell is a good successor to the now deprecated netsh
- you want to enable the remote desktop group in a language and windows version neutral way, not just port 3389
Some registry entries:
[HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\Services\SharedAccess\Parameters\FirewallPolicy\FirewallRules]
[HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\SharedAccess\Parameters\FirewallPolicy\FirewallRules]
"RemoteDesktop-UserMode-In-TCP"="v2.28|Action=Allow|Active=TRUE|Dir=In|Protocol=6|LPort=3389|App=%SystemRoot%\\system32\\svchost.exe|Svc=termservice|Name=@FirewallAPI.dll,-28775|Desc=@FirewallAPI.dll,-28756|EmbedCtxt=@FirewallAPI.dll,-28752|"
"RemoteDesktop-UserMode-In-UDP"="v2.28|Action=Allow|Active=TRUE|Dir=In|Protocol=17|LPort=3389|App=%SystemRoot%\\system32\\svchost.exe|Svc=termservice|Name=@FirewallAPI.dll,-28776|Desc=@FirewallAPI.dll,-28777|EmbedCtxt=@FirewallAPI.dll,-28752|"
"RemoteDesktop-Shadow-In-TCP"="v2.28|Action=Allow|Active=TRUE|Dir=In|Protocol=6|App=%SystemRoot%\\system32\\RdpSa.exe|Name=@FirewallAPI.dll,-28778|Desc=@FirewallAPI.dll,-28779|EmbedCtxt=@FirewallAPI.dll,-28752|Edge=TRUE|Defer=App|"
"RemoteAssistance-In-TCP-EdgeScope"="v2.28|Action=Allow|Active=TRUE|Dir=In|Protocol=6|Profile=Public|App=%SystemRoot%\\system32\\msra.exe|Name=@FirewallAPI.dll,-33003|Desc=@FirewallAPI.dll,-33006|EmbedCtxt=@FirewallAPI.dll,-33002|Edge=TRUE|Defer=App|"
"RemoteAssistance-Out-TCP"="v2.28|Action=Allow|Active=TRUE|Dir=Out|Protocol=6|Profile=Public|App=%SystemRoot%\\system32\\msra.exe|Name=@FirewallAPI.dll,-33007|Desc=@FirewallAPI.dll,-33010|EmbedCtxt=@FirewallAPI.dll,-33002|"
"RemoteAssistance-PnrpSvc-UDP-In-EdgeScope"="v2.28|Action=Allow|Active=TRUE|Dir=In|Protocol=17|Profile=Public|LPort=3540|App=%systemroot%\\system32\\svchost.exe|Svc=pnrpsvc|Name=@FirewallAPI.dll,-33039|Desc=@FirewallAPI.dll,-33040|EmbedCtxt=@FirewallAPI.dll,-33002|Edge=TRUE|Defer=App|"
"RemoteAssistance-PnrpSvc-UDP-OUT"="v2.28|Action=Allow|Active=TRUE|Dir=Out|Protocol=17|Profile=Public|App=%systemroot%\\system32\\svchost.exe|Svc=pnrpsvc|Name=@FirewallAPI.dll,-33037|Desc=@FirewallAPI.dll,-33038|EmbedCtxt=@FirewallAPI.dll,-33002|"
–jeroen
