The Delphi styling mechanism hard codes style paths for Delphi built-in styles.
During compilation, a .VRC file is generated for your project (in this example ProjectName.vrc which is a resource compiler script. This was introduced by Delphi 2007 (see: Pre-build trick does not work to circumvent [BRCC32 Error] xxx.vrc(1): error creating xxx.res (via: Embarcadero Discussion Forums & StackOverflow)), got extended over time and by now this script can includes at least:
- version info
- main icon
- manifest reference
- platform targets
- supported styles
For the latter, you can get errors like this one:
[BRCC32 Error] ProjectName.vrc(63): file not found: C:\Users\Public\Documents\RAD Studio\10.0\Styles\SlateClassico.vsf
The solution to this error is simple:
- Go to your project options
- Switch to “All Targets”
- Go to node “Application”, then “Appearance”
- Look for the style named just in front of the
.vsfextension (in this caseStateClassico) - Remove the checkmark.
- Press OK
- Rebuild
Example files :
/* ----- VS_VERSION.dwFileFlags ----- */
#define VS_FF_DEBUG 0x00000001L
#define VS_FF_PRERELEASE 0x00000002L
#define VS_FF_PATCHED 0x00000004L
#define VS_FF_PRIVATEBUILD 0x00000008L
#define VS_FF_INFOINFERRED 0x00000010L
#define VS_FF_SPECIALBUILD 0x00000020L
#define VS_FFI_FILEFLAGSMASK 0x0000003FL
/* ----- VS_VERSION.dwFileOS ----- */
#define VOS_UNKNOWN 0x00000000L
#define VOS_DOS 0x00010000L
#define VOS_OS216 0x00020000L
#define VOS_OS232 0x00030000L
#define VOS_NT 0x00040000L
#define VOS_WINCE 0x00050000L
#define VOS__BASE 0x00000000L
#define VOS__WINDOWS16 0x00000001L
#define VOS__PM16 0x00000002L
#define VOS__PM32 0x00000003L
#define VOS__WINDOWS32 0x00000004L
#define VOS_DOS_WINDOWS16 0x00010001L
#define VOS_DOS_WINDOWS32 0x00010004L
#define VOS_OS216_PM16 0x00020002L
#define VOS_OS232_PM32 0x00030003L
#define VOS_NT_WINDOWS32 0x00040004L
/* ----- VS_VERSION.dwFileType ----- */
#define VFT_UNKNOWN 0x00000000L
#define VFT_APP 0x00000001L
#define VFT_DLL 0x00000002L
#define VFT_DRV 0x00000003L
#define VFT_FONT 0x00000004L
#define VFT_VXD 0x00000005L
#define VFT_STATIC_LIB 0x00000007L
1 VERSIONINFO
FILEVERSION 1, 0, 124, 56
PRODUCTVERSION 1, 0, 0, 0
FILEFLAGSMASK VS_FFI_FILEFLAGSMASK
FILEOS VOS__WINDOWS32
FILETYPE VFT_APP
{
BLOCK "StringFileInfo"
{
BLOCK "040904E4"
{
VALUE "FileVersion", "1.0.124.56\000\000"
VALUE "ProductVersion", "1.0.0.0\000\000"
VALUE "ProductName", "My server\000\000"
VALUE "CompanyName", "My company\000\000"
}
}
BLOCK "VarFileInfo"
{
VALUE "Translation", 1033, 1252
}
}
and
MAINICON ICON "MyProject_Icon.ico"
1 24 "MyProject.$manifest"
PLATFORMTARGETS RCDATA {1}
SlateClassico VCLSTYLE "C:\\Users\\Public\\Documents\\RAD Studio\\10.0\\Styles\\SlateClassico.vsf"
–jeroen
