Archive for the ‘ESP8266’ Category

GitHub – JanDerogee/TeleJukebox: A project based on the concepts of the Wonderfoon and Arduinofoon

Posted by jpluimers on 2021/11/18

[Wayback/Archive.is] GitHub – JanDerogee/TeleJukebox: A project based on the concepts of the Wonderfoon and Arduinofoon which simplfies the design of the Wonderfoon keeping the most important music playback feature down to

a simple PCB in a small case where you plug the phone in

The completed project works very simple:

  • Pick up the phone, you hear the “dial tone” MP3, Dial a number, you hear the MP3 0..9 playing (depending on the dialed number), When the song is over, you hear the “disconnected” MP3, You can dial another number and hear another song or hang up the phone.
  • Some phones also have a button on the front. When you press this button, the phone randomly playes one of the songe 0..9 and when that song is over, it automatically plays a new song, randomly. This will allow the person on the phone to continuously listen to the music. This may be of help to those who can’t figure out how it works but love to hear the songs over and over again.
  • You can configure the music folder from which the MP3s are played, you can use up to 10 different folders
  • You can configure the volume of the device
  • Configurations are done through the phone itself (dial 738 OR hold the button while picking up the handpiece), you hear a voice that guides you through a menu and all you need to do is dial in your settings value.

You can power this design through a USB port cable. This way the device can be fed using a simple mobilephone charger OR be connected to the PC. When connected to a PC, the TeleJukebox identifies itself like a USB-stick and you can easily modify the file without removing the card from the system. Meaning that you do no even need to open the case in order to change the collection of MP3 files. Keep in mind that when the device is in USB-stick mode, it cannot playback MP3 files meaning that in this mode it will not act like a TeleJukebox.

Music rights

Especially when using this in a professional environment. be sure the music that plays is rights free (there are music therapists for treating people with Alzheimer’s and dementia that can help you with that).

Steps, reasoning, and building instructions

A less in depth Dutch article (with 13 minute explaining video below) explaining most of the steps and all the reasoning is this multi-part one:

  1. [Wayback] .Build – Bouw een Wonderfoon – Bouw een Wonderfoon voor iemand anders – Achtergrond – Tweakers

    It works with these and younger phones as long as they can do pulse-dialing:

    De T65, W65 en T65 TDK

  2. [Wayback] .Build – Bouw een Wonderfoon – Wat is een Wonderfoon? – Achtergrond – Tweakers

    The small regular and debug boxes under the PTT/KPN phone connector box:

    .Build Wonderfoon - Twee keer TeleJukebox

  3. [Wayback] .Build – Bouw een Wonderfoon – Een goedkopere variant – Achtergrond – Tweakers
  4. [Wayback] .Build – Bouw een Wonderfoon – Slopen is zonde – Achtergrond – Tweakers

    Both boards with electronics soldered:

    .Build Wonderfoon - Beide varianten van de TeleJukebox

    The non-debug board with components to be soldered:

    .Build Wonderfoon - Onderdelen TeleJukebox

  5. [Wayback] .Build – Bouw een Wonderfoon – T65 bewerken – Achtergrond – Tweakers

    The small cleanup and modification steps (shorting the microphone) for the T65 phone:

    .Build Wonderfoon - Contact haakT65 schoonmaken.Build Wonderfoon - Contact haakT65 schoonmaken

    .Build Wonderfoon - Aansluitingen T65.Build Wonderfoon - Aansluitingen T65.Build Wonderfoon - Aansluitingen T65.Build Wonderfoon - Aansluitingen T65

  6. [Wayback] .Build – Bouw een Wonderfoon – Solderen maar! – Achtergrond – Tweakers

    Schematics:

    .Build Wonderfoon - Schema TeleJukebox

    Shopping list:

    – 1x Pcb of perf board (€ 1,01)
    – 1x Arduino Pro Micro (€ 7,95)
    – 1x DFPlayer mp3-speler(€ 0,73)
    – 1x TIL111 optocoupler (€ 0,41)
    – 2x Weerstand 4K7 Ohm (€ 0,16)
    – 7x Weerstand 2K7 Ohm (€ 0,56)
    – 1x Weerstand 560 Ohm (€ 0,08)
    – 1x Elco 1000 µF 6.3 V (€ 0,23)
    – 1x Condensator 330nF (€ 0,13)
    – 1x Condensator 100nF (€ 0,05)
    – 2x Led (€ 0,06)
    – 1x USB, type B, pcb (€ 0,67)
    – 1x Tactile switch (€ 0,09)
    – 1x Pinheader, male, 6 breed (€ 0,03)
    – 4x Jumper kabel, female (€ 1,95)
    – 1x Micro sd-kaart (€ 2,50)
    – 1x PTT-wandcontactdoos (€ 2,99)
    – 1x Behuizing (€ 1,22)
    Totaal € 20,82

    Voor de compacte pcb kun je de switch, een led, een weerstand van 2k7 Ohm en de twee weerstanden van 4k7 Ohm weglaten.

  7. [Wayback] .Build – Bouw een Wonderfoon – Voor wie gaat hij worden? – Achtergrond – Tweakers

    The inside of the non-debug box:

    .Build Wonderfoon - TeleJukebox



Wonderfoon got more versatile

Note that the most recent Wonderfoon products got more versatile allowing more songs, warnings for taking pills, and ring-reminders based on morse code.

[Wayback] Home | Wonderfoon

. De Wonderfoon-Centrale

–jeroen

Read the rest of this entry »

Posted in Arduino, Arduino, Development, ESP32, ESP8266, ESP8266X, Hardware, Hardware Development, Hardware Interfacing, Raspberry Pi, Software Development | Leave a Comment »

Remote power control your IoT hardware and remote updating boot SD cards

Posted by jpluimers on 2020/07/16

Thomas Rini (of U-Boot and Yocto fame) mentioned these solutions for remote power control of IoT devices and remote updating SD cards in this slide State of the U-Boot – Thomas Rini, Konsulko Group:

Two power solutions I like myself are:

The combination of these allows for really flexible production and testing environments.

Slides at [WayBackELC2017 – State of the U-Boot.pdf

–jeroen

Read the rest of this entry »

Posted in Arduino, Development, ESP8266, ESP8266X, Hardware Development, Hardware Interfacing, IoT Internet of Things, Network-and-equipment, Odroid, Power User, Raspberry Pi | Leave a Comment »

18650 Battery shield V3(RaspberryPi&Arduino) from lspoplove on Tindie

Posted by jpluimers on 2020/03/04

As you know Tesla has thousands of 18650 batteries. The 18650 battery is a strong existence. So we made this 18650 battery shield for maker.

Features:

  • Battery protection(Over charge or Over discharge)
  • Micro USB port Input
  • Type-A USB Output
  • 0.5A current charging
  • 1 switch control USB output
  • 5~8V Input Voltage
  • 3V & 1A Output
  • 5V & 2A Output
  • LED indicate(Green means full,Red means charging)
  • 3V output port x3
  • 5V output port x3

Charging can only be done at 0.5A, so using it as a sort of UPS seems not possible, but an interesting device nonetheless.

The other products referenced from the same page are interesting too and will undoubtedly bring me some new ideas for some projects.

Source: [WayBack18650 Battery shield V3(RaspberryPi&Arduino) from lspoplove on Tindie

Via:

–jeroen



Posted in 18650, Arduino, Batteries, Development, ESP8266, Hardware Development, Li-Ion, Odroid, Power User, Raspberry Pi | Leave a Comment »

Sonoff Wireless Switch Family Gets a $3 IP66 Waterproof Enclosure

Posted by jpluimers on 2019/07/15

Interesting stuff from a while back that I will be using soon: [WayBack] Sonoff Wireless Switch Family Gets a $3 IP66 Waterproof Enclosure.

Pictures via CNX Software; originally found via [WayBack] $2.90 waterproof case for +ITEAD Studio Sonoff switches… – Jean-Luc Aufranc – Google+

–jeroen

Read the rest of this entry »

Posted in Development, ESP8266, Hardware Development, IoT Internet of Things, Network-and-equipment, Power User | Leave a Comment »

Relays and Arduino / ESP8266 / ESP8266X

Posted by jpluimers on 2019/06/19

As a follow-up on Raspberry Pi and relays – follow up on Having one Raspberry Pi reset another Raspberry Pi through relay or transistor some of my research links to bring this to Arduino, ESP8266, ESP8266X and similar devices:

–jeroen

Posted in Arduino, Development, ESP8266, ESP8266X, Hardware Development | Leave a Comment »
